2012 GMC Savana 3500 specs & colors

Full-size Cargo Van

Change trim

$29,915

Starting MSRP
Current listing price

2012 GMC Savana 3500

Showing the 2012 GMC Savana 3500 RWD 3500 135"

Shop Now

Key specs

3-door

1 seat

324.0-hp, 6.0-liter, 8 Cylinder Engine (Flex Fuel Capability)

0 combined MPG

Vehicle length and height not available

Rear Wheel Drive

Color options

Exterior

Interior

Neutral

Medium Pewter

Packages

Specifications

Highlights

Gas/Ethanol V8

Engine Type

-

MPG

280 hp
324 hp

Horsepower

1

Seating Capacity

Brakes

Pwr

Brake Type

4-Wheel

Brake ABS System

Not Available

Brake ABS System (Second Line)

Yes

Disc - Front (Yes or )

Yes

Disc - Rear (Yes or )

12.8 x 1.5 in

Front Brake Rotor Diam x Thickness

13.0 x 1.1 in

Rear Brake Rotor Diam x Thickness

Not Available

Drum - Rear (Yes or )

Electrical

600

Cold Cranking Amps @ 0° F (Primary)

105

Maximum Alternator Capacity (amps)

Engine

Gas/Ethanol V8

Engine Type

4.8L/293

Displacement

280 @ 5200

SAE Net Horsepower @ RPM

295 @ 4600

SAE Net Torque @ RPM

6-Speed A/T
Transmission Overdrive Switch
A/T

Transmission Options

-

MPG

13.6 qts

Total Cooling System Capacity

Measurements

N/A

Ext'd Cab Cargo Volume

270 ft³

Cargo Volume

N/A

Tailgate Width

53 in

Cargo Box (Area) Height

53 in

Cargo Box Width @ Wheelhousings

N/A

Cargo Box Width @ Floor

N/A

Cargo Area Width @ Beltline

N/A

Cargo Box Width @ Top, Rear

125 in

Cargo Area Length @ Floor to Seat 1

154 in

Cargo Area Length @ Floor to Console

21 in

Step Up Height - Side

20 in

Step Up Height - Front

44 in

Side Door Opening Width

48 in

Side Door Opening Height

57 in

Rear Door Opening Width

49 in

Rear Door Opening Height

8 in

Ground Clearance, Rear

9 in

Ground Clearance, Front

40 in

Front Head Room

41 in

Front Leg Room

69 in

Front Shoulder Room

66 in

Front Hip Room

N/A

Second Head Room

N/A

Second Leg Room

N/A

Second Shoulder Room

N/A

Second Hip Room

135 in

Wheelbase

224 in

Length, Overall w/rear bumper

N/A

Length, Overall

79 in

Width, Max w/o mirrors

82 in

Height, Overall

40 in

Overhang, Front

N/A

Overhang, Rear w/o bumper

28 in

Ground to Top of Load Floor

N/A

Cab to End of Frame

2

Passenger Capacity

Safety

Standard

Stability Control

Steering

N/A

Turning Diameter - Wall to Wall

Pwr-Assisted

Steering Type

N/A

Steering Ratio (:1), Overall

49 ft

Turning Diameter - Curb to Curb

Suspension

Coil Spring

Suspension Type - Front

Hypoid Multi-Leaf

Suspension Type - Rear

Independent

Axle Type - Front

Full-Floating

Axle Type - Rear

Tires & Wheels

LT245/75R16E

Front Tire Size

LT245/75R16E

Rear Tire Size

LT245/75R16E

Spare Tire Size

16 x 6.5 in

Front Wheel Size

16 x 6.5 in

Rear Wheel Size

16 x 6.5 in

Spare Wheel Size

Steel

Front Wheel Material

Steel

Rear Wheel Material

Steel

Spare Wheel Material

Weight & Capacity

9,600 lbs

Gross Vehicle Weight Rating

0 lbs

Total Option Weight

5,206 lbs

Curb Weight

10,384 lbs

Gross Axle Weight Rating

5,206 lbs

As Spec'd Curb Weight

4,394 lbs

As Spec'd Payload

4,394 lbs

Maximum Payload Capacity

13,000 lbs

Gross Combined Wt Rating

5,000 lbs

Dead Weight Hitch - Max Trailer Wt.

500 lbs

Dead Weight Hitch - Max Tongue Wt.

7,400 lbs

Wt Distributing Hitch - Max Trailer Wt.

1,110 lbs

Wt Distributing Hitch - Max Tongue Wt.

Not Available lbs

Fifth Wheel Hitch - Max Trailer Wt.

Not Available lbs

Fifth Wheel Hitch - Max Tongue Wt.

10,000 lbs

Maximum Trailering Capacity

31 gal

Fuel Tank Capacity, Approx

Not Available gal

Aux Fuel Tank Capacity, Approx

N/A

Base Curb Weight

2,915 lbs

Curb Weight - Front

2,291 lbs

Curb Weight - Rear

0 lbs

Option Weight - Front

0 lbs

Option Weight - Rear
