2011 Ford Ranger XL specs & colors
Regular Cab Pickup
MSRP
- 2WD Reg Cab 112" XL
- $18,160
- 2WD Reg Cab 112" XLT
- $19,120
- 2WD Reg Cab 118" XL
- $19,445
- 2WD 2dr SuperCab 126" XL
- $19,855
- 2WD 2dr SuperCab 126" XLT
- $20,740
- 2WD 2dr SuperCab 126" Sport
- $22,425
- 2WD 4dr SuperCab 126" XLT
- $22,640
- 2WD 4dr SuperCab 126" Sport
- $23,495
- 4WD 2dr SuperCab 126" XL
- $23,905
- 4WD 4dr SuperCab 126" XLT
- $25,060
- 4WD 4dr SuperCab 126" Sport
- $26,070
$18,160
Starting MSRP
Current listing price
Current listing price
Showing the 2011 Ford Ranger 2WD Reg Cab 112" XL
Shop NowKey specs
Color options
Interior
Medium Dark Flint
Black
Packages
$0
Starting MSRP
Specifications
Highlights
|
Gas I4
Engine Type
|
|
19 City / 24 Hwy
MPG
|
|
143 hp
Horsepower
|
|
3
Seating Capacity
|
Brakes
|
Pwr
Brake Type
|
|
4-Wheel
Brake ABS System
|
|
Not Available
Brake ABS System (Second Line)
|
|
Yes
Disc - Front (Yes or )
|
|
Yes
Disc - Rear (Yes or )
|
|
11.28 x 0.39 in
Front Brake Rotor Diam x Thickness
|
|
11.85 x 0.39 in
Rear Brake Rotor Diam x Thickness
|
|
Not Available
Drum - Rear (Yes or )
|
Electrical
|
540
Cold Cranking Amps @ 0° F (Primary)
|
|
100
Maximum Alternator Capacity (amps)
|
Engine
|
Gas I4
Engine Type
|
|
2.3L/140
Displacement
|
|
143 @ 5250
SAE Net Horsepower @ RPM
|
|
154 @ 3750
SAE Net Torque @ RPM
|
|
M/T
A/T 5-Speed A/T 5-Speed M/T Transmission Options
|
|
19 City / 24 Hwy
MPG
|
|
7.2 qts
Total Cooling System Capacity
|
Measurements
|
3
Passenger Capacity
|
|
39 in
Front Head Room
|
|
42 in
Front Leg Room
|
|
55 in
Front Shoulder Room
|
|
53 in
Front Hip Room
|
|
N/A
Second Head Room
|
|
N/A
Second Leg Room
|
|
N/A
Second Shoulder Room
|
|
N/A
Second Hip Room
|
|
112 in
Wheelbase
|
|
189 in
Length, Overall w/o rear bumper
|
|
N/A
Length, Overall w/rear bumper
|
|
N/A
Length, Overall
|
|
69 in
Width, Max w/o mirrors
|
|
66 in
Height, Overall
|
|
34 in
Overhang, Front
|
|
44 in
Overhang, Rear w/o bumper
|
|
82 in
Cab to End of Frame
|
|
30 in
Ground to Top of Load Floor
|
|
9 in
Ground Clearance, Front
|
|
9 in
Ground Clearance, Rear
|
|
73 in
Cargo Box Length @ Floor
|
|
54 in
Cargo Box Width @ Top, Rear
|
|
54 in
Cargo Box Width @ Floor
|
|
41 in
Cargo Box Width @ Wheelhousings
|
|
17 in
Cargo Box (Area) Height
|
|
52 in
Tailgate Width
|
|
37 ft³
Cargo Volume
|
|
Not Available ft³
Ext'd Cab Cargo Volume
|
Safety
|
Standard
Stability Control
|
Steering
|
Pwr Rack & Pinion
Steering Type
|
|
N/A
Steering Ratio (:1), Overall
|
|
38 ft
Turning Diameter - Curb to Curb
|
|
40 ft
Turning Diameter - Wall to Wall
|
Suspension
|
SLA w/Coil Springs
Suspension Type - Front
|
|
2-Stage Multi-Leaf
Suspension Type - Rear
|
|
Twin-Forged SLA
Axle Type - Front
|
|
Ford Semi-Floating
Axle Type - Rear
|
Tires & Wheels
|
P225/70R15
Front Tire Size
|
|
P225/70R15
Rear Tire Size
|
|
Mini
Spare Tire Size
|
|
15 x 7 in
Front Wheel Size
|
|
15 x 7 in
Rear Wheel Size
|
|
Mini in
Spare Wheel Size
|
|
Steel
Front Wheel Material
|
|
Steel
Rear Wheel Material
|
|
Steel
Spare Wheel Material
|
Weight & Capacity
|
N/A
Base Curb Weight
|
|
1,752 lbs
Curb Weight - Front
|
|
1,384 lbs
Curb Weight - Rear
|
|
0 lbs
Option Weight - Front
|
|
0 lbs
Option Weight - Rear
|
|
3,136 lbs
As Spec'd Curb Weight
|
|
1,164 lbs
As Spec'd Payload
|
|
1,164 lbs
Maximum Payload Capacity
|
|
4,800 lbs
Gross Combined Wt Rating
|
|
1,500 lbs
Dead Weight Hitch - Max Trailer Wt.
|
|
150 lbs
Dead Weight Hitch - Max Tongue Wt.
|
|
1,500 lbs
Wt Distributing Hitch - Max Trailer Wt.
|
|
225 lbs
Wt Distributing Hitch - Max Tongue Wt.
|
|
Not Available lbs
Fifth Wheel Hitch - Max Trailer Wt.
|
|
Not Available lbs
Fifth Wheel Hitch - Max Tongue Wt.
|
|
N/A
Maximum Trailering Capacity
|
|
17 gal
Fuel Tank Capacity, Approx
|
|
Not Available gal
Aux Fuel Tank Capacity, Approx
|
|
4,750 lbs
Gross Axle Weight Rating
|
|
3,136 lbs
Curb Weight
|
|
0 lbs
Total Option Weight
|
|
4,300 lbs
Gross Vehicle Weight Rating
|
